Overview

Sporting a new sleek case, the new ACR38T-D1 SIM-Sized Smart Card Reader is a small USB device that delivers more than what meets the eye. A powerful reader that packs a lot in feature despite its size, it has all the functionalities of a standard-sized ACR38 PC-Linked Reader, and supports ISO 7816 cards, MCU cards, memory cards, and GSM 11.11-compliant cards.

ACR38T-D1 has PC/SC and CCID compliance that make for its seamless interoperability and use across different platforms, particularly in PC environments. With its short circuit protection feature, it guarantees safe and durable usage all the time.

Weighing nothing more than your standard USB stick, ACR38T-D1 is a device you can bring anywhere to keep smart card technology right at your fingertips.

Features

• Supports ISO 7816 Class A, B and C (5 V, 3 V, 1.8 V) card
• Supports CAC (Common Access Card) *
• Supports PIV (Personal Identity Verification) Card*
• Supports microprocessor cards with T=0 or T=1 protocol
• Supports memory cards:
  • Cards following the I2C bus protocol (free memory cards), including:
  • Atmel: AT24C01 / 02 / 04 / 08 / 16 / 32 / 64 / 128 / 256 / 512 / 1024
  • SGS-Thomson: ST14C02C, ST14C04C
  • Gemplus: GFM1K, GFM2K, GFM4K, GFM8K
• Cards with intelligent 256 bytes EEPROM and write protect function, including: SLE4432, SLE4442, SLE5532, SLE5542
• Cards with intelligent 1K bytes EEPROM and write-protect function, including: SLE4418, SLE4428, SLE5518, SLE5528
• Cards with '104' type of EEPROM non-reloadable token counter cards, including: SLE4406, SLE4436, SLE5536, SLE6636
• Cards with secure memory IC with password and authentication, including: AT88SC153, AT88SC1608
• Cards with Intelligent 416-Bit EEPROM with internal PIN check, including: SLE4404
• Cards with Security Logic with Application Zone, including: AT88SC101, AT88SC102, AT88SC1003
• Supports PPS (Protocol and Parameters Selection)
• Features Short Circuit Protection
• Application Programming Interface:
  • Supports PC/SC
  • Supports CT-API (through wrapper on top of PC/SC)

Application

• e-Government
• e-Banking  and e-Payment
• e-Healthcare
• Public Key Infrastructure
• Network Security
• Access Control
• Loyalty Program
