Retail Pos TITAN S Series

  • Intel Braswell Celeron N3160 or Bay Trail Celeron N2807 CPU
  • Energy Efficient and Low Heat Generation Architecture
  • Slim Display, Sleek Chassis and Small Foot Print Design
  • 15" LED LCD Display With True-Flat PCAP Touch
  • IP55 dust and Water Proof Front Panel
  • Superior Serviceability and Easy Installation
  • Fanless Operation and No Ventilation Hole
  • Supporting M.2 SSD
  • Microsoft Azure Certified
Retail Pos TITAN S series

Feature Gallery

Key Features

5th Gen "Braswell" Intel Celeron

Stylish Design with Two Tore Colors

IP55 Proof Front Panel

15" LED LCD Display with PCAP Touch

Easy Access to SSD/HDD

Simple Assembling Structure

Option

Traditional Bezel & True Flat

VFD

9.7" Rear Display

15" Rear Display

V Stand

MSR

VESA Wall Mount

Onboard M.2 SSD

Specification

Titan S 200
System CPU intel Celeron N3160
(Quad Core upto 2.24GHz)
Storage HDD:320GBGB
SSD: 256GB/128GB/64GB
M.2: 256GB/128GB/64GB
Ram DDRIII 1 slot (Up to 8GB)
Display LCD 15" LED Backlight LCD (1024 x 768)
Touch PCAP Touch / 5W Resistive Touch
Interface Serial 3 Ports (R/5V/12V BIOS Selectable)
(1 Port: RS-422/485 (Jumper Selectable))
Parallel 1 Port (Factory Option)
USB 2.0: 4 Ports/ 3.0: 2 Ports
Ethernet 1 Port
VGA 1 Port
Drawer 1 Port / 2CH(12V/24V Selectable)
Audio 1 Port (Line Out)
Optional MSR 1/2/3 Track Support (USB)
Rear Display VFD (20H x 2Line, 256 x 32 Graphic)
LCD(9.7", 15"(Touch Option))
Wall Mount VESA Wall Mount
Stand V Stand
Software OS POSReady 7 /Windows 8.1 Industry Retail /Windows 10 Iot Enterprise
Power Supply DC 12V/5A(60W)
Dimensions 379(W) x 264(H) x 362(D) mm
Weight 6.0kg
Color Black+White, Black, White
Certification CF / FCC / CB / cTUVus(NRTL) / RoHs
